Product Overview
The Garrett Pro-Pointer AT is a fully waterproof, handheld metal detector designed for pinpointing metallic objects. It features audio and vibration alerts, automatic detection of all metals, and adjustable sensitivity settings. Suitable for underwater use up to 10 feet, it includes a belt holster and operates on a 9V battery.
1.1 Key Features and Benefits
The Garrett Pro-Pointer AT offers advanced features like three sensitivity levels and two detection modes: Audio-plus-Vibrate or Vibrate-only. It is fully waterproof, operating up to 10 feet underwater, and includes a built-in ruler for measuring target depth. The device automatically detects all metals, providing both audible and vibration alerts. Its ergonomic design and adjustable settings ensure precise detection, making it ideal for various environments. The Pro-Pointer AT is durable, user-friendly, and enhances metal detection efficiency.
1.2 Design and Build Quality
The Garrett Pro-Pointer AT boasts a sleek, ergonomic design with a durable, weather-resistant construction. It is fully waterproof, with an IP66 rating, and operates seamlessly in harsh environments. The device features a robust build, ensuring long-term reliability. Its lightweight design enhances comfort during extended use, while the intuitive controls provide easy access to settings. The inclusion of a built-in ruler for measuring target depth adds practicality, making it a versatile tool for professional and amateur metal detecting.
Technical Specifications
The Garrett Pro-Pointer AT operates at 12 kHz, uses a 9V battery, and features IP66 water and dust resistance, suitable for diverse environments with a built-in ruler.
2.1 Performance Metrics
The Pro-Pointer AT delivers precise detection with a 12 kHz operating frequency, ensuring effective identification of both ferrous and non-ferrous metals. Its proportional audio and vibration alerts increase in intensity as targets near, enhancing accuracy. The device offers three sensitivity levels, allowing customization for various environments. It also features automatic retuning, ensuring consistent performance across diverse conditions, making it reliable for both beginners and experienced users alike.
2.2 Environmental and Operational Ratings
The Pro-Pointer AT is IP 66 rated, offering robust protection against dust and water jets. It operates effectively in temperatures ranging from -37°C to 70°C, ensuring reliability in extreme conditions. The device is fully submersible up to 3 meters, making it ideal for underwater exploration. Its durable construction and weather-resistant design ensure long-lasting performance in challenging environments, whether on land or in water.
Operating Modes
The Pro-Pointer AT offers two detection modes: Audio-plus-Vibrate and Vibrate-only. These modes enhance versatility, allowing users to customize alerts for different environments and preferences, ensuring effective detection.
3.1 Detection Settings: Audio-plus-Vibrate vs. Vibrate-only
The Pro-Pointer AT features two detection settings: Audio-plus-Vibrate and Vibrate-only. The Audio-plus-Vibrate mode provides both sound and vibration alerts, ideal for noisy environments. In contrast, Vibrate-only mode offers silent operation, suitable for stealth or quiet settings. Both modes ensure clear feedback, with intensity increasing as the detector nears the target, allowing users to customize alerts based on their operational needs and preferences. This dual functionality enhances versatility in various detecting scenarios.
3.2 Sensitivity Levels and Adjustment
The Pro-Pointer AT offers three sensitivity levels, adjustable to optimize detection performance. To access Adjustment Mode, press and hold the button for 2 seconds, indicated by a single beep and flashing LED. Sensitivity levels are cycled through by pressing the button, with LED and beep indicators: one beep for low, two for medium, and three for high. Higher sensitivity enhances depth but may increase false signals in mineralized soil. The manual provides detailed guidance for fine-tuning settings.
Adjustments and Customization
The Pro-Pointer AT allows users to customize sensitivity levels, detection modes, and operational settings. Adjustments are made via the button, enabling personalized performance tuning. The manual guides detailed customization options for enhanced usability.
4.1 Entering Adjustment Mode
To enter adjustment mode, press and hold the button for two seconds. This is indicated by a single beep, followed by a dual-tone beep and a flashing LED. Once in adjustment mode, users can modify settings such as sensitivity levels and detection preferences. The process is straightforward, allowing quick customization to suit different environments and user preferences. The manual provides detailed steps for entering and navigating this mode effectively.
4.2 Fine-Tuning Sensitivity and Detection Settings
Once in adjustment mode, sensitivity levels can be fine-tuned using the button. The device offers three sensitivity settings, indicated by LED colors: green (low), amber (medium), and red (high). Detection settings allow users to choose between Audio-plus-Vibrate or Vibrate-only modes. To select Vibrate-only, press and hold the button while powering on. Adjustments are saved automatically when the device is turned off, ensuring customized performance for various detecting conditions. This feature enhances accuracy and usability in diverse environments.
Maintenance and Care
Regularly clean the device with a soft cloth and store it in a dry place. Remove the battery for long-term storage to prevent leakage and ensure optimal performance.
5.1 Cleaning and Storage Tips
Clean the Pro-Pointer AT with a soft, damp cloth to remove dirt or debris. Store it in a cool, dry place, away from direct sunlight. Remove the battery during long-term storage to prevent leakage. Regularly inspect the device for wear and tear, ensuring all components remain functional. Proper care extends the device’s lifespan and maintains its performance for reliable metal detection in various environments.
5.2 Battery Replacement and Management
To replace the battery, rotate the battery compartment cover counterclockwise and remove the old 9V battery. Insert the new battery, ensuring proper alignment, then rotate the cover clockwise to secure it. For optimal performance, use high-quality batteries and avoid mixing old and new ones. Turn off the device when not in use to extend battery life. Store batteries in a cool, dry place, away from extreme temperatures.
Accessories and Compatibility
The Garrett Pro-Pointer AT includes a holster, 9V battery, and manual. It is compatible with Z-Lynk wireless technology, enabling connection to devices like Garrett MS-3 headphones.
6.1 Included Accessories: Holster, Battery, and Manual
The Garrett Pro-Pointer AT comes with essential accessories, including a durable holster for convenient carrying, a 9V battery to ensure long-lasting operation, and a detailed manual. The manual provides comprehensive instructions for setup, usage, and troubleshooting, ensuring users can maximize the device’s capabilities. These included items enhance the overall user experience, making the detector ready to use right out of the box.
6.2 Compatibility with Wireless Devices (e.g., Z-Lynk Technology)
The Garrett Pro-Pointer AT is compatible with Z-Lynk Technology, enabling seamless wireless connectivity to devices like the Garrett MS-3 Wireless Headphones or WR-1 Z-Lynk receiver. This allows for real-time audio signal transmission, enhancing detection convenience. The Z-Lynk module simplifies pairing, ensuring a reliable connection up to 6 inches. Wireless integration streamlines metal detection, offering a modern, efficient experience for users in various environments.
Troubleshooting Common Issues
Check sensitivity settings to avoid false signals and ensure proper battery installation. Address interference by adjusting settings or replacing batteries to maintain optimal performance and accuracy.
7.1 Resolving False Signals and Interference
To resolve false signals, adjust the sensitivity settings to a lower level and ensure the device is away from metal objects. Interference can be minimized by avoiding areas with electromagnetic sources. If issues persist, resetting the device or replacing the battery may help restore accurate detection. Regular cleaning and proper storage also contribute to maintaining optimal performance and reducing false alarms.
7.2 Addressing Battery Life Concerns
To address battery life concerns, ensure the 9V battery is fresh and properly installed. Clean the battery contacts to maintain good connectivity. Avoid extreme temperatures, as they can drain the battery faster. Reduce unnecessary feature usage, like continuous audio signals, to conserve power. Store the device in a cool, dry place when not in use to prolong battery health and performance.
Manual Contents
The manual includes a quick start guide and detailed operating instructions, helping users understand features, settings, and troubleshooting for the Garrett Pro-Pointer AT metal detector.
8.1 Quick Start Guide
The quick start guide provides essential steps to begin using the Garrett Pro-Pointer AT, including turning it on, adjusting sensitivity, and understanding detection modes. It covers basic operations like activating the device, interpreting alerts, and optimizing settings for different environments. Designed for rapid familiarization, the guide ensures users can start detecting metal efficiently, with clear instructions for initial setup and operation.
8.2 Detailed Operating Instructions
The detailed operating instructions provide a comprehensive guide to using the Garrett Pro-Pointer AT, covering advanced features like sensitivity adjustment, detection modes, and battery management. It explains how to interpret audio and vibration signals, optimize settings for different environments, and perform routine maintenance. The manual also includes troubleshooting tips and technical specifications to ensure optimal performance in various conditions, including underwater use.
Z-Lynk Wireless Technology
Z-Lynk Wireless Technology integrates seamlessly with Garrett MS-3 Wireless Headphones and WR-1 Z-Lynk devices, enhancing detection by providing real-time audio feedback without wired connections.
9.1 How Z-Lynk Enhances Detection
Z-Lynk Wireless Technology enhances detection by enabling real-time audio feedback through compatible devices like Garrett MS-3 Wireless Headphones or WR-1 Z-Lynk. It eliminates cords, reducing tangled wires and detection time. The technology ensures clear, uninterrupted signals, improving accuracy and user experience. Wireless connectivity also minimizes false signals, allowing focus on target identification. This seamless integration optimizes metal detection efficiency in various environments.
9.2 Pairing and Connecting Devices
Pairing Z-Lynk devices is straightforward. Turn on the receiver (e.g., Garrett MS-3 Headphones or WR-1 Z-Lynk) and hold the Pro-Pointer AT within 6 inches. Press and hold the button for 2 seconds until a dual-tone beep confirms pairing. The LED flashes during pairing. Once connected, the detector and receiver sync automatically, ensuring reliable wireless communication. Refer to the manual for detailed steps to ensure a secure and stable connection.
Battery Management
The Garrett Pro-Pointer AT uses a 9V battery. Replace by turning the battery compartment counterclockwise, removing the old battery, and installing a new one. Ensure proper alignment and secure the compartment clockwise. For optimal performance, use high-quality alkaline batteries and avoid fully draining the battery to prolong its lifespan. Refer to the manual for detailed instructions on replacement and care.
10.1 Replacing the 9V Battery
To replace the battery in your Garrett Pro-Pointer AT, first turn the battery compartment cover counterclockwise to remove it. Carefully extract the old 9V battery and dispose of it properly. Insert the new battery, ensuring the terminals align correctly. Replace the compartment cover and tighten it clockwise until secure. Avoid over-tightening to prevent damage. Use only high-quality alkaline batteries for optimal performance and longevity of your device;
10.2 Optimizing Battery Life
To extend the battery life of your Garrett Pro-Pointer AT, always turn it off when not in use. Adjust sensitivity and detection settings to minimize unnecessary power consumption. Use the automatic shutdown feature to conserve energy if the device is inactive. Avoid extreme temperatures and store the battery separately in a cool, dry place. For optimal performance, use high-quality alkaline batteries and replace them as soon as power levels drop significantly.
Best Practices for Use
Turn on the Garrett Pro-Pointer AT by pressing the button while holding it away from metal objects. Adjust sensitivity and detection settings as needed. Use the 9V battery for optimal performance and take advantage of its 10-foot underwater capability.
11.1 Tips for Effective Metal Detection
Adjust sensitivity settings for optimal performance in varying environments. Use the audio-plus-vibrate mode for clear alerts or switch to vibrate-only in silent situations. Retune the device for accurate target detection. Fully utilize the 10-foot underwater capability for water searches. Regularly check and replace the 9V battery for consistent operation. Store the device in the included holster to protect it during transport. Follow these tips for enhanced metal detection efficiency and reliability.
11.2 Safety Precautions and Usage Guidelines
Always handle the Garrett Pro-Pointer AT with care to avoid damage. Use the device in environments within its operational temperature range of -37°C to 70°C. Keep it away from flammable materials. Ensure the battery compartment is sealed properly before underwater use. Avoid exposing the device to extreme impacts or temperatures. Follow manufacturer guidelines for battery replacement and storage to maintain performance and longevity. Proper care ensures safe and effective use across various conditions and environments.
